BiRec MLED MVLED cannot be dimmed
1. Delete the hand transmitter
Keep the STOP key, UP key, DOWN key as well as the learning key P on the reverse side pressed. The status display is lit briefly twice orange-green and then red. The hand transmitter/s is/are deleted from the receiver
2. Set the receiver to programming mode
Briefly disconnect the receiver from the power supply and then reconnect it
3. Select the channel on the hand transmitter
Select the desired channel on the hand transmitter (standard: channel 1)
4. Press the programming key for at least 3 seconds
Press the programming key for at least 3 seconds. The awning moves respectively up for 4 seconds and then down for 4 seconds (cycle). This cycle is repeated for max. 2 minutes and is terminated early if the receiver has been successfully programmed.
5. Programming process when closing
Press the UP key (within 1 second of closing)
6. Programming process when opening
Press the DOWN key (within 1 second of opening)
7. Change to light programming process
Select the channel for the LED lighting
8. Press the programming key for at least 3 seconds
9. Programming process when lighting up 100%
Press the UP key (within 1 second). If successfully programmed, the LEDs switch off directly. The LEDs are then lit again with 100%, do NOT press ANY key now!
10. Programming process when lighting up 50%
Press the DOWN key (within 1 second). If successfully programmed, the lighting switches off!
If the lighting still flashes, please repeat Step 9.
